PRODUCTS
DBL-W01 Dry Bulk Container Liner
Dry Bulk Container Liner, also known as bulk container bag or container liner, is a professional flexible packaging solution designed for the transportation and storage of dry bulk goods.
COLOR
Customization Available
SIZE
Customization Available
Specification & Application(For granule transportation)
Product Overview
Dry Bulk Container Liner, also known as bulk container bag or container liner, is a professional flexible packaging solution designed for the transportation and storage of dry bulk goods. Made of 140gsm HDPE (High-Density Polyethylene) woven fabric, it features high tensile strength, wear resistance, moisture resistance and corrosion resistance, effectively protecting bulk goods from contamination, moisture and damage during long-distance sea, land and air transportation. It is widely used in agriculture, chemical industry, construction, mining and other fields, replacing traditional rigid packaging and reducing transportation and packaging costs.
Product Specifications
| Parameter | Detailed Specification |
| Product Name | Dry Bulk Container Liner |
| Material | 140gsm HDPE Woven Fabric (High-Density Polyethylene), food-grade optional |
| Fabric Thickness | 0.18-0.22mm (based on 140gsm density) |
| Tensile Strength | Warp: ≥ 1800N/5cm; Weft: ≥ 1500N/5cm (meets international transportation standards) |
| Elongation at Break | Warp: ≤ 15%; Weft: ≤ 18% |
| Moisture Resistance | Waterproof rate ≥ 98%, effectively isolating external moisture and humidity |
| Load Capacity | 10-30 tons (customizable according to container size and goods weight) |
| Available Sizes | Customized for 20ft/40ft/40HQ standard dry containers; length: 5-12m, width: 2.3-2.5m, height: 2.3-2.6m |
| Color | White (standard), blue, black, green (customizable with minimum order quantity) |
| Accessories | Loading spout (top), discharge spout (bottom), reinforced edges, lifting loops (4-8 pcs, HDPE material, load-bearing ≥ 5 tons each) |
| Certifications | ISO9001, FDA (food-grade), REACH, RoHS (environmental compliance) |
Product Features
- High Strength & Durability: 140gsm HDPE woven fabric has excellent tensile and tear resistance, can bear heavy bulk goods (up to 30 tons) without deformation or damage, and is wear-resistant to resist friction during transportation.
- Moisture & Dust Proof: The dense HDPE woven structure effectively isolates external moisture, humidity, dust and pollutants, keeping the internal bulk goods dry and clean, avoiding caking or contamination.
- Lightweight & Cost-Effective: Lightweight design (per unit weight ≤ 30kg) reduces transportation weight and cost; reusable design saves packaging costs compared with disposable packaging.
- Easy Loading & Unloading: Equipped with top loading spout and bottom discharge spout, which can realize rapid loading and unloading of bulk goods, improve work efficiency and reduce labor costs.
- Customizable Design: Supports customization of size, color, load capacity and accessories (such as anti-static, anti-UV, food-grade lining) to meet the needs of different bulk goods and transportation scenarios.
- Environmental Protection: HDPE material is non-toxic, odorless, recyclable and environmentally friendly, complying with international environmental protection standards, and can be recycled after use.
Product Application
Main Application Fields & Goods
- Agricultural Products: Transportation and storage of grains (wheat, corn, rice, soybeans), seeds, feed, fertilizers, pesticides, cotton, etc. The moisture-proof and dust-proof performance ensures the quality of agricultural products.
- Chemical Industry: Packaging and transportation of non-toxic and non-corrosive chemical bulk goods, such as plastic particles, resin, chemical powder, soda ash, salt, etc. The corrosion-resistant HDPE material avoids chemical reactions and ensures transportation safety.
- Construction & Mining Industry: Transportation of construction materials (cement, sand, gravel, lime, gypsum powder), mineral products (coal, ore powder, quartz sand), etc. The high load-bearing capacity and wear resistance adapt to harsh transportation environments.
- Food Industry: Food-grade dry bulk container liner (with FDA certification) is used for transportation of food bulk goods, such as sugar, flour, starch, milk powder, coffee beans, etc., ensuring food safety and hygiene.
- Other Fields: Also applicable to the transportation of other dry bulk goods, such as animal feed, wood chips, plastic scraps, etc., providing a safe and efficient packaging solution.
Application Scenarios
Suitable for standard dry containers (20ft/40ft/40HQ) in sea freight, land freight and air freight; widely used in international trade, domestic long-distance transportation, warehouse storage and other scenarios. It is an essential packaging product for bulk goods logistics, especially for large-volume, long-distance transportation of dry bulk goods.
