TP-04 Thermal Pallet Cover (Aluminum Foil/Woven PE/Aluminum Foil)

Specification & Application

Product Overview

The Thermal Pallet Cover is a high-performance thermal insulation packaging product designed for palletized temperature-sensitive goods. Adopting a 3-layer composite structure of Aluminum Foil / Woven PE / Aluminum Foil, it combines excellent thermal insulation, tear resistance, moisture protection and load-bearing capacity. It is widely used in logistics transportation and storage scenarios, effectively maintaining the stable temperature of goods, preventing quality damage caused by temperature fluctuations, and providing reliable protection for palletized goods during long-distance transportation (sea, land, air freight).

Product Specifications

Product Name：Thermal Pallet Cover

Material Structure：3-layer composite: Outer layer – Aluminum Foil; Intermediate layer – Woven PE; Inner layer – Aluminum Foil

Food-grade, non-toxic, environmental friendly

Aluminum Foil Thickness：12-15μm；High thermal reflectivity (≥95%), waterproof, moisture-proof

Woven PE Thickness：80-120μm；High tensile strength, tear-resistant, load-bearing

Total Thickness：102-150μm；Customizable according to demand

Temperature Retention Range：Maintain -20℃ ~ 30℃ for 12-48 hours (ambient temperature 25℃)；Extend to 72 hours with ice packs

Waterproof Performance：100% waterproof, moisture-proof, anti-fog；Isolate external humidity and water vapor

Tensile Strength：≥15N/15mm；Resistant to tearing during transportation and handling

Available Sizes：Standard: 120x100x200cm, 140x120x220cm, 160x140x240cm；Customizable for all standard pallet sizes (EU/US standard pallets)

Color：Silver (aluminum foil surface)；Custom color available for large orders

Certifications：FDA, LFGB, ISO9001；Compliant with food contact and international logistics standards

Weight per Unit：200-500g (depending on size and thickness)；Lightweight, no extra transportation burden

Product Features

– Superior Thermal Insulation: Double aluminum foil layers (inner and outer) effectively reflect radiant heat, while the intermediate woven PE layer traps static air to form a thermal insulation barrier, blocking internal and external temperature transfer and maintaining the stable temperature of palletized goods.

– Durable & Tear-Resistant: The woven PE middle layer has high tensile strength and tear resistance, which can withstand the friction and impact during loading, unloading and transportation, preventing the cover from being damaged and ensuring long-term use.

– All-Round Protection: 100% waterproof and moisture-proof aluminum foil layers isolate external humidity, water vapor and pollutants, protecting goods from moisture erosion; the full coverage design wraps the entire pallet, avoiding dust and contamination.

– Lightweight & Easy to Use: Lightweight design does not increase the transportation weight and cost; it can be quickly unfolded and wrapped around the pallet, fixed with drawstrings or adhesive tapes, saving labor and time.

– Customizable & Versatile: Support custom sizes, thicknesses and printed logos (outer layer), suitable for all standard pallets; compatible with various transportation methods and climate environments.

– Cost-Effective: Reusable (if not damaged), easy to fold and store when not in use, reducing packaging costs for long-term use.

Product Applications

Main Application Scenarios

1. Food & Beverage Industry: Used for packaging and transporting palletized frozen food (meat, seafood, ice cream), fresh produce (fruits, vegetables), dairy products (milk, yogurt), and beverages (beer, juice). It maintains the freshness of food and avoids spoilage caused by temperature changes during logistics.
2. Pharmaceutical Industry: Suitable for the transportation and storage of temperature-sensitive medical products, such as vaccines, biological reagents, precision medicines, etc., which need strict temperature control (2-8℃ or -18℃), ensuring the efficacyand safety of the products.
3. Electronics & Chemical Industry: Used for packaging palletized precision electronic components (lithium batteries, semiconductors) and heat-sensitive chemical raw materials (perfumes, dyes), preventing performance degradation caused by temperature fluctuations and humidity.
4. Logistics & Warehousing: Ideal for short-term storage and long-distance transportation of palletized temperature-sensitive goods, especially in sea freight and land freight, where temperature changes are large, providing stable thermal insulation protection.
5. Daily Consumer Goods: Applicable to the transportation of palletized thermal-sensitive daily products (cosmetics, skin care products), ensuring product quality during logistics and storage.
